Features:
128 K's data buffer RAM
Support for low-delay time pure data transmission and full/half-duplex flow control
Built-in watch-dog timer to monitor any error in internal data exchange

Interface:
1 x Ethernet port (RJ45) 10/100Base-Tx
1 x Optical port (Single SC) 100Base-Fx

Optical Port:
1310nm Single mode
Transfer Distance: up to 20km
Connectors: Single SC connector
Fiber core: 8.3um, 8.7um, 9um and 10um on single mode fiber
Optical Power (dBm): -15~ -8
Receiving Sensitivity (dBm): ≤-34

Ethernet Port:
Standard: IEEE 802.3, IEEE 802.3u
Available speed: auto-detective 10/100Mbps Full-Duplex and Half-Duplex auto-negotiation
Connectors: RJ-45 connector; MDI/MDI-X connection auto-sensing

LED Indicators:
FX, TX, Link/Act(Left/Right), FDX, PWR
FX: Light on when fiber speed is 100Mbps, while “OFF” means the rate is 10 Mbps
TX: Light on when TP speed is 100Mbps, while “OFF” means the rate is 10 Mbps
Link/ACT: Left side is indicate for fiber port link/act and right side for TP,light flashing when data transmitting and receiving
FDX: Light on when TP full-duplex mode is active,light off when TP half-duplex mode is active
PWR: Light on when DC power on, else light off

Power Requirement:
Output voltage: AC 220V or DC5V 1A
Power dissipation: ≤1 watts

Physical Characteristics:
Housing: Metal enclosure
Volume: 94x70x26mm (LxWxH)

Environmental Limits:
Operating Temperature: 0°C to 60°C
Storage Temperature: -20°C to 70°C
Humidity: 5% to 90% RH

Checklist:
Before you installing the Converter,verify that the package contains the following:
1.The Ethernet Media Converters
2.AC/DC Power Adapter
3.User’s Manual
