☁ Camera test monitor Packing List:

camera CCTV Tester *1
AC/DC Adapter *1
Power Output Cable *1
Transformer *1
A/V Cable *1
Video Cable *1
Date Cable *1
Wristbands*1


☁1. video tester
Video System: NTSC/PAL Automatically recognize
Video level: 1VPP
Display screen: 5 inch LCD RGB 480 * 272 (QVGA) resolution, 64K color
Screen adjustment: Video display brightness, contrast, color saturation adjustable,
LCD backlight brightness adjustable
Video input / output: 1 channel BNC Video IN
☁2. HD AHD ，TVI , CVI Test
SD signal Format: NTSC,PAL
Video signal: HD AHD,TVI,CVI,CVBS
Resolution :Max 8MP，
MAX Support 8MP AHD 20FPS ; 8MP TVI 20FPS, 8MP CVI
Signal Level: 1Vpp
☁3. 12V power output
Power output:
Temporary power output 12V 1A
USB*1 5V1A output
☁4. Audio test
Audio test: Input audio signal, and played on the internal speaker
☁5. Power supply
External power supply: DC 5V（2A）
Battery-powered: Built-in 3.7V li-polymer battery, Capacity 2600mAh
Charge: Charge time 3-4 hours Battery power time 8 hours
Power saving features: Low power consumption, automatic power off, Real-time display of battery level
☁6. System settings
Language settings: English
Auto power off: Disable / 5-60 minutes
☁7.Cable test
cable test: Test any two or more wire cable Display connect sequence and remote number
LED Light: 1*35lm LED light
Working environment and Specifications: -20℃---+70℃/30%-90%R
