Feature

imple fashion body, light and portable
uses 8 inch high resolution (1024x768) TFT LCD screen, the image is clear and exquisite, colourful
support for BNC input for professional security monitoring equipment is connected, so that signal mutual interference reduction, can achieve the best signal effect
support chromatic Ypbpr input,color more vivid, the image more realistic
video mode input switching, Support multi-channel video reception, high sensitivity, strong interference resistance
support for VGA input, can be used for computer liquid crystal display (640*480/60Hz, 800*600/60Hz, 1024*768/60Hz)
Support high-definition HDMI input
built-in high-quality loudspeakers
support image flip up and down control, adapt to different installation mode
with timing switch machine and automatic signal standby function
Support USB interface to charge (5 volt 1 amp)


Specfication

Panel size: 8 inch digital display
Video input: 3Vp-p CVBS
Aspect ratio: 4:3
Resolution: 1024 x 768
Effective viewing area: 162 x 121 mm
Viewing angle: 120°(H)/100°(V)
Panel lifetime: 10,000 hours
Brightness: 250cd/m2
Contrast ration: 300:1
Response time: 12ms
Power input: DC12V-1000mA
Power mode support: Power adapter
Adjustable stand: Landscape
Speaker: 1W(max)*1
OSD Menu Language options: ENGLISH RUSSIAN PORTUGAL SPAIN DETCH FRANCE ITALY CHINESE
Temperature range (operation): 0-40 centigrade degree


Package Included

1x8"Monitor
1xPower adapter
1xStand
1xUser's manual
