Up to 200000Lux large range
It has large LCD display with back light and bar graph.
Support auto power off
Max/Min and data hold are available

Specifications:


1) Automatic and manual range switching;
2) Inquiry function for maximum and minimum values;
3) Data hold function;
4) Peak value measurement function;
5) Relative value measurement function;
6) Zero calibration function;
7) 3 1/2 bit LCD display, with analog bar display;
8) Fc/Lux unit conversion function;
9) Outrange indication (When the measured value exceeds the current range, LCD will display the signal OL to indicate that the range is overreached);
10) High precision. Measurement range (0.00~200000Lux);
11) Low battery indicator;
12) Touch tone and mute function;
13) Auto power-off function (The machine will be powered off automatically keys are not operated for more than 10 minutes)
14) Compact design, durable, and portable.

Technical Data:

1) Temperature range:
2) Operation:-10~50 C, max 80 % HR(Non-Condensed)
Storage:-10~50 C,max 80 % HR (Non-Condensed) (removing batteries)
3) Sampling rate: >=2 times/s
4) Display: 3½ digits, max reading of 1999, with analog bar display;
5) Sensor: silicon photoelectric diode
6) Measured spectral range: 320~730nm
7) Measurement ranges: 20, 200, 2000, 20000, 200000 Lux 20, 200, 2000, 20000 FC
8) Operating environment: indoor use
9) Height: 2000m highest
10) Battery life: Approx. 200 hours
11) Power supply: 1¡Á9 V,IEC 6LR61
12) Dimensions (H¡ÁW¡ÁD): 190 mm¡Á89 mm¡Á42.5 mm
13) Weight: Approx. 360 g without batteries
Approx. 420 g with batteries
Unit conversion for illuminance scales
1 Fc = 10.764 lux
1 lux = 0.09290 Fc
