Feature:

1. Can capture HDMI video and HDMI audio at the same time, and can transmit audio and video signals to computers and smart phones for preview and storage, it is suitable for high‑definition acquisition, teaching recording, health care imaging, etc.

2. Display advantages, video supports HDMI local loop output, which can be performed simultaneously using multiple displays, high resolution brings you a brand new visual experience, supports maximum input resolution up to 4K, supports maximum output resolution up to 1080P.

3. When supporting the use of standard AWG26 cables, the input transmission distance is up to 15 meters, (resolution of 1080P and below) can satisfy the whole house coverage.

4. Supports most acquisition software, for VLC/OBS/Amcap, etc, and supports for Windows/Android/MacOS, with a high degree of compatibility and integration to make your life easier.

5. Compliant with USB video UVC specification, compliant with USB audio UAC specification, saving you from worrying about safety and liberating you.

6. Portable, small size and easy to carry, no complicated wire hole and easy operation, make your life be clear at a glance.

Specification:

Condition: 100% Brand New

Item Type: HDMI Video Capture

Color: Black

Material: ABS Plastic

HDMI Resolution: 4K for Maximum Input

Video Input Format: 8/10/12 bit Color Depth

Video Output Mode: YUV, JPEG

Video Output Resolution: Maximum Output Resolution 1080P

Support Audio Format: L-PCM

Input Cable Length: ≤15meters / 49.2ft, AWG26 HDMI Standard Cable

Maximum Working Current: 0.7A/5VDC

Operating Temperature Range: -10-55℃

Weight: Approx.102g/3.6oz

Body Size: Approx. 5.8x5.5x1.8cm/2.3x2.2x0.7in

USB Power Cable: Approx. 80cm/31.5in

USB Male to Male Cable Length: Approx.80cm/31.5in
