System
Operation Interface : Web; Local GUI
AI by Recorder：Face detection, face recognition, perimeter protection, and SMD Plus
AI by Camera：Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
Audio and Video
Access Channel : 8 channels
Network Bandwidth :
AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing
AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing
Resolution : 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF
Multi-screen Display :1st Screen: 1/4/8/9 ; 2nd Screen: 1/4/8/9
Compression Standard
Video Comp: Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Audio Compre: G.711a; G.711u; PCM; G726
Network
Network Protocol : HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register
Mobile Phone Access: iOS; Android
Browser : Chrome; IE9 and later; Firefox
Recording Playback
Multi-channel:Up to 8 channels
Record Mode :General, motion detection; intelligent; alarm
Backup Method :USB device and network
Playback Mode :Instant playback, general playback, event playback, tag playback, smart playback
Port
Audio Input : 1-channel
Audio Output ：1-channel RCA
HDD Interface ：1 SATA port, up to 16 TB.The maximum HDD capacity varies with environment temperature.
USB ：2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
HDMI :1
VGA :1
Network Port :1 (10/100/1000 Mbps Ethernet port, RJ-45)
PoE Port :8 ports, 10/100 Mbps, IEEE 802.3 af/at
General
Power Supply :53 VDC, 1.812 A
Power Consumption: Total output of NVR is <10 W(without HDD) Total output power of PoE is 72W,the maximum output power of asingle port is 25.5W
