Important

1. This is a reader only, it can not write, please pay attention
2. This reader only work at 13.56 Mhz, supporting Mi fare 1k, M4k, Ultraight, UltralightC, Ntag213/ 215/ 216, MIfare Plus 2k/ 4k， Mifare Desfire 2k/ 4k /8k ,do not support othey type of cards

3. it is a HID keyboard compliance device, which is driver free (plug and play), no need software, 10 digit DEC ID number will auto-output at the cursor similar like a keyboard

Physical

1. Dimension: 104 mm (L) x 68 mm (W) x 10 mm (H)
2. Material: ABS enclosure
3. Color: Black
4. Cable: 1.0 meter USB cable
5. Weight: 100 gram
6. Protocol: IEC14443A

Electrical

1. Working Frequency: 13.56 MHz
2. Read distance: 3- 10 cm ( for ISO card size)
3. Card support: MF1k, MF4k, Ultraight, UltralightC, Ntag213/ 215/ 216, MF Plus 2k/ 4k， MF Desfire 2k/ 4k /8k
3. Reading time: < 100 ms
4. Interface: USB 1.1
5. Power supply: 5V/ 100 mA from USB port

6. Output Format: 10 digit Decimal ( converted from Chip UID (UID 3 to UID 0)
7. Driver free,Windows XP, Vista,7, 8, 10 supported.

Environment

1. Working: -10 C to +60 C, 5~ 95% RH, no condensation
2. Storage: -25 C to + 45 C, 5~ 95% RH, no condensation
Packing

1. 1x Reader
1. 1x USB cable
