Features:

No load power consumption <0.2W for 35W/50W; <0.3W for 75W/100W

Universal AC input / Full range

Withstand 300VAC surge input for 5 seconds

Ultra compact and 1U low profile

Withstand 5G vibration test

High operating temperature up to 70oC

Protections: Short circuit / Overload / Over voltage

Cooling by free air convection

Compliance to IEC/EN60335-1(PD3) and IEC/EN61558-1,-2-16 for household appliances

Operating altitude up to 5000 meters

High efficiency, long life and high reliability

LED indicator for power on

Low cost

3 years warranty

General Specification (Please refer to images below for detailed datasheet)

AC input voltage range:85~264VAC; 120~370VDC

AC inrush current (max.):Cold start, 45A at 230VAC

DC adjustment range:±10% by potentiometer

Overload protection Range:110%~150%

Overload protection Type:Hiccup mode, auto-recovery

Over voltage protection Range:115%~135% rated output voltage

Over voltage protection Type:Shut down o/p voltage, re-power on to recover

Withstand voltage:3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.25kVAC, 1 minute

Working temperature:-30~+70°C (refer to output derating curve)

Safety standards:UL60950-1, IEC/EN60950-1, IEC/EN61558-1, EN61558-2-16, IEC/EN60335-1, CCC GB4943 approved

EMC standards:EN55022 class B, EN55014, EN61000-3-2, 3, EN61000-4,2,3,4,5,6,8,11, GB9254

Connection:5P/9.5mm pitch terminal block

Dimension (LxWxH):99x 97x 30
