Features:
Waterproof,conforms to IP68
Strong Zinc Alloy Electroplated anti-vandal case
Full programming from the keypad
2000 users,Supports Card, PIN, Card + PIN
Can be used as a stand alone keypad
Backlight keys
Wiegand 26 input for connection to external reader or Wiegand 26 output for connection to a controller
Adjustable door output time,alarm time,door open time
Very low power consumption (30mA)
Fast operating speed,<20ms with 2000 users
Lock output current short circuit protection
Easy to install and program
Built-in light dependent resistor (LDR) for anti tamper
Build-in buzzer
Red,yellow and green LEDs display the working status
Support four digits worked as stand-alone keypad

Specifications:
Operating Voltage : DC12V
User Capacity: 2000
Card Reading Distance: 5~8cm / 2"-3.1"
Current: <30mA (Standby); <60mA (Active)
Lock Output Load: <3A
Alarm Output Load: <20A
Operation Temperature: -45℃~60℃ / -49℉~140℉
Operating Humidity: 10%~90% RH
Waterproof: Conforms to IP68
Adjustable Door Relay time: 0~99 seconds
Wiegand Interface: Wiegand 26 bit
Wiring Connections: Electric Lock,Exit Button,External Alarm,External Reader
Compatible Cards: EM standard card (Can't support some encrypted cards,such as HID, Cobra, APCiK, etc)
Frequency: 125khz
Dimension: Approx. 120(W)x58(H)x22(D)mm / 4.7"x2.3"x0.9"
Net Weight: Approx. 371g / 0.82lb

Package includes:
1 x Metal Access Control
1 x Installation Kit
1 x User Manual
